TOUGHLIQUID Ultra 240 All-In-One Liquid Cooler TOUGHLIQUID Ultra 240 All-In-One Liquid Cooler TOUGHLIQUID Ultra 240 All-In-One Liquid Cooler TOUGHLIQUID Ultra 240 All-In-One Liquid Cooler TOUGHLIQUID Ultra 240 All-In-One Liquid Cooler TOUGHLIQUID Ultra 240 All-In-One Liquid Cooler
TOUGHLIQUID Ultra 240 All-In-One Liquid Cooler

TOUGHLIQUID Ultra 240 All-In-One Liquid Cooler

In stock
CL-W322-PL12GM-A / CL-W322-PL12GM-B
TOUGHLIQUID Ultra 240 AIO Cooler is an all-in-one liquid cooler with our latest LCD display that presents real-time information of the system and even plays GIF files with 480*480 resolution. It’s also equipped with TOUGHFAN 12 Turbo fans to provide outstanding cooling results while maintaining minimal audible noise.

2.1 Inch Rotational LCD Display

A 2.1 Inch Rotational LCS Display that presents real-time information and even play JPG and GIF files with 480*480 resolution, bringing great visual aesthetics and highly customizable functions to your All-in-One cooler.

Caution: The cap can only rotate from 0 to 270 degrees.
(See here)

TOUGHFAN 12 Turbo Equipped

Equipped with two TOUGHFAN 12 Turbo fans, the TOUGHLIQUID Ultra 240 boosts the fan speed up to 2500 RPM, ensuring the best cooling results whether you’re working or gaming.

High-Performance Cold Plate

The high-performance copper base plate accelerates heat conductivity. The high-quality and reliable pump enables maximum water circulation, keeping the copper plate continuously cool. The low evaporation tube effectively decreases the loss of coolant; therefore, no refill is required.

Fully Customizable with TT RGB Plus 2.0

Monitor frequency and real-time temperature directly from our 2.1 inch LCD Display, and upload any image or GIF file to add extra flair with the TT RGB Plus 2.0 software.
Caution: The TOUGHLIQUID Ultra Series is only supported by the TT RGB Plus 2.0.

Check out more animated GIFs for your AIO displays here.

Start-up & Standby Screen Setting

TT RGB PLUS 2.0 Software

The new version of Thermaltake’s TT RGB PLUS patented software, providing more lighting effects and PC monitoring functions.

TT RGB PLUS 2.0 and TT RGB PLUS 1.0 will overwrite one another; users can only install one version of TT RGB PLUS.


Sync with Razer Chroma Lighting

All Thermaltake TT RGB PLUS products are able to connect into the Razer Chroma ecosystem, Razer Synapse 3. Users can experience synchronized gaming and RGB lighting effects on their TT RGB PLUS liquid cooling system and Razer gaming gear!


Works with Amazon Alexa

All Thermaltake TT RGB PLUS products support Amazon Alexa Voice Service, allowing you to give voice commands to the Alexa-enabled devices.


TT AI Voice Control

Give you full control over the TT RGB PLUS products with your voice. “SyncALL, Say”Hello TT”.

Note: TT AI Voice control and Amazon Alexa requires the use of at least one TT RGB PLUS software-enabled product to function.

More Information
P/N CL-W322-PL12GM-A / CL-W322-PL12GM-B
Pump Motor Speed : 3200 RPM
Rated Voltage : 12V
Rated Current : 0.38A
Power Input : 4.56W
CPU Display Rated Voltage : 5 V
Power Input : 1.15 W
Display Type : 2.1” TFT-LCD (IPS)
Display Resolution : 480x480 (RGB) px
Display Support Interface : Micro USB to USB (9PIN)
System Compatibility : Windows 7 / 8 / 8.1 / 10
Water Block Material : Copper
Fan Dimension : 120 x 120 x 25 mm
Speed : PWM 500~2500 R.P.M (2510-4PIN)
Noise Level : 28.1 dB-A
Power Input : 2.76 W (one fan)
Rated Voltage : 12 V
Rated Current : 0.23A (one fan)
Max. Air Flow : 72.69 CFM (one fan)
Max. Pressure : 3.78 mm-H2O (one fan)
Tube Length : 400 mm
Material : Rubber
Radiator Dimension : 273 x 120 x 27 mm
Material : Aluminum
Compatibility Intel LGA 2066/2011-3/2011/1700/1200/1156/1155/1151/1150

User Manual

  • File Name
  • รายละเอียด
  • Size
  • Version
  • Release Date

Drivers & Software

  • File Name
  • รายละเอียด
  • Size
  • Version
  • Release Date
  • TT RGB PLUS Software
  • 1.Add TOUGHRAM XG D5 25th Hydrangea.
    2.Add LCD rotate function. (SETTINGS)
    3.Add new function 2.1-inch LCD “INFO”.
    4.Add new Function 2.1-inch LCD “TEXT”.
    5.Fixed the error language writings.
    6.Fixed DPS G PSU fan speed maximum error.
    7.Update HWiNFO kit.
    8.Made minor bug fixes and system performance improvements.
  • V2.1.6
  • 2023-12-27
